05What the live signal chain actually contains

A real-time video chain starts at a sensor or a tape deck, passes through a capture device, a computer or a hardware mixer, a scaler or converter, and ends at a projector or a display. Every hop adds a small delay, and the delays do not simply add up in a straight line: some stages buffer whole frames, others only a few lines. A capture card that holds two frames at 60 Hz costs about 33 milliseconds before any processing begins. A software compositor running at 60 Hz adds at least one more frame. A projector with internal scaling can add one to three frames depending on the model and the input mode. The useful habit is to write the chain down and mark each stage with its measured or documented delay. Where a figure is not published, measure it: point a camera at a stopwatch, route the signal through the chain, and photograph both the source and the screen in the same frame. The difference is the end-to-end latency, and it is the only number that matters to a performer reacting to their own image. For readers who want a working example of how this chain is discussed in practice, a French review titled La Mire covers live audiovisual performance with a focus on what the direct signal does to the image, including signal treatment, projection in the room, and tape playback at the desk.

06Which trade-offs does latency force on a live setup?

Latency is a budget, and every stage spends from it. The first trade-off is resolution against delay: a 4K capture path usually buffers more data than a 1080p path, and the extra pixels rarely help when the image is projected at a modest size. The second is software against hardware: a computer gives you flexible compositing but adds frames, while a hardware mixer adds almost nothing but limits what you can do. The third trade-off is monitoring. If the performer watches a delayed screen, they are playing to the past. Many setups solve this by giving the performer a direct, undelayed feed on a small monitor while the audience sees the processed image. The delay then becomes a deliberate offset rather than an accident, and it can be tuned: a few frames read as tight, a second reads as a distinct echo. The fourth is audio. Sound and image drift apart quickly once the video path passes roughly 100 milliseconds. If the audio is also being processed, the two chains must be aligned at the output, not at the source.

07Color bars and signal treatment as image material

Color bars are not only a calibration tool. In a live context they are a known reference: a stable pattern that lets you verify black level, white level, and chroma before the audience arrives. A scope or a histogram on the bars tells you whether the projector is clipping highlights or crushing blacks, and it tells you this in seconds rather than after twenty minutes of guessing. Beyond calibration, the signal itself can be treated as material. Gain, offset, feedback loops, and analog-style distortion all operate on the electrical or digital representation rather than on a depicted subject. This is a different way of thinking about image making: the picture is the result of the processing, not a window onto something else. The practical consequence is that the setup must be stable enough to be repeatable, because a treatment that cannot be reproduced cannot be rehearsed. Documenting the treatment matters as much as performing it. Note the order of operations, the parameter values, and the point in the chain where the treatment is inserted.

08How does projection in a room change the image?

Projection is where the signal meets architecture. Throw distance, image size, and screen material determine brightness and contrast more than most settings menus do. The basic relationship is that doubling the image width quarters the illuminance on the surface, so a large image needs either a brighter projector or a darker room. Screen material changes the result as well. A matte white surface reflects evenly and preserves color, while a grey surface lowers black level at the cost of overall brightness. Translucent surfaces, including smoke, water, and fabric scrims, transmit and reflect at the same time, which produces a double image: one on the surface, one behind it. That effect depends on the angle of view, so the audience position becomes part of the design. The room itself contributes. Ambient light from exits, windows, or stage fixtures raises the black level and flattens contrast. A projector placed off-axis introduces keystone, and correcting it digitally costs resolution.

09What about tape, Hi8, and digitization at the desk?

Magnetic tape remains in use because it imposes a discipline that file playback does not. A tape has a fixed duration, a physical position, and a sound of its own. Hi8 and similar formats carry a characteristic texture, and the transport mechanism introduces small timing variations that are part of the result. Digitizing tape at the desk requires a stable capture path and a consistent time base. The common approach is to capture through a time base corrector or a capture device that tolerates the small sync errors of consumer tape, then record to a format that does not drop frames. The protocol matters: set the capture format before the session, verify audio and video alignment on a known segment, and label each file with the tape identifier and the counter position. For live use, the tape is often played back rather than pre-digitized, because the performer wants the transport under their hand.

10A short checklist before the doors open

Write the chain down, from source to surface, and mark the delay at each stage. Measure the end-to-end latency with a stopwatch and a camera. Align audio and video at the output. Verify black and white levels on color bars. Check the projected image from the worst seat in the room, not the best. Confirm that the performer's monitor is not delayed. Label every tape and every capture file. Keep a written record of the settings, because the next session will start from that record rather than from memory. None of this requires expensive equipment.
